| 1 | Network Supported | 3 x Built-in module, Support mode: TDD-LTE, FDD-LTE, WCDMA 1 x USB interface external module, Support mode: TDD-LTE、FDD-LTE、WCDMA 1 x Ethernet 10M/100M: Local network port |
| 2 | Input | Video: Input port: HDMI or SDI Input format: PAL/NTSC Audio: One stereo: HDMI/SDI, LINE IN |
| 3 | Encoding | Video: Encoder standards: H.264 A / D accuracy: 8bit Supported resolutions: 720*480, 720*576,1280*720,1920*1080 Bit rate：0.5～12Mbps Audio: Encoding standards：AAC Sampling bit rate:48KHz Encoding rate:128Kbit/s, Two-channel |
| 4 | System Latency | 2000ms |
| 5 | Control | Touch Screen Control, remote control from server |
| 6 | Physical Specifications | Size: 36x97x155 mm Weight: 0.6Kg Power supply: Internal Battery: 1h External Power source: DC9 16V/2A Power dissipation: 15W |
| 7 | Working environment | Operating Temperature: -10～30℃ Operating Humidity: 5%～90%（noncondensable） Stock Temperature: -20℃～60℃； Stock Humidity: 0%～95%（noncondensable） |
